Features:
1. Equipped with Panasonic servo motor system and precision electric cylinder multi-axis positioning technology, the displacement accuracy is 0.5 level and the transmission is stable;
2. 2-8 working areas can be customized, and the areas can work simultaneously or be tested separately;
3. The test module can be manually adjusted up and down and is suitable for samples with different strokes;
4. Sensors with different force value specifications can be purchased and equipped with corresponding fixtures for testing to meet the testing needs of different sizes and styles.
Software features:
1. Use PLC machine online control to effectively avoid interference of circuit boards, servo drives, etc. on test data;
2. The controller adopts the company's independently developed force value testing software, with optional languages such as English and Chinese, and the operation is intuitive and convenient;
3. It will automatically stop after the test is completed and can work alone for a long time;
4. Power-off memory, damage detection, limit protection, overload protection and other designs ensure safer operation.
Parameter
| capacity | 200kg imported sensor | driver | 400w servo drive | ||||
| Electric cylinder | Stroke 500mm, speed 5~250mm/s | Control mode | PLC control | ||||
| Dimensions | 2000*800*1950mm (L*W*H) | ||||||
| Power source | 1∮. AC 220V. 50Hz | Electric machine | 400w servo motor | ||||
| Test force value | 50-1200N | Sample size | Extension length 150-500mm | ||||
| Unit switching | gf/kgf/N | weight | Approx. 200kg | ||||
