Scope of application:
This product is used for the preparation of test pieces for testing the peel strength and stickiness of adhesive tapes, protective films, and release film products. With a fixed pressure and speed, the adhesive tape sample is standardized and evenly adhered to the standard test substrate.
Product parameter table
Appearance material | Fine imitation marble paint + stainless steel |
Display method | LED counter display |
Rolling speed | 25W speed regulating motor, 300mm/min |
Rolling load | 2000±50g |
Covering rubber thickness | 6mm |
The diameter of the roller covered with rubber | 84±1mm |
Wheel width | 45mm metal wheels |
Rubber hardness | Hs80±5 |
N umber of rounds | Group 2 |
Counter | LED, 0~999.999 |
Dimensions | (L×W×H) 520*400*250mm |
Weight | 27kg |
Power supply | 1∮,AC220V,1A |
