Product advantages:
1. Our company was awarded the title of Guangdong High-tech Enterprise
2. Our company has passed ISO9001:2015 quality management system certification
3. This series of products has obtained the Guangdong High-tech Product Certificate (Programmable High and Low Temperature Tensile Testing Machine)
4. This series of products has obtained a utility model patent certificate (a high and low temperature tensile testing machine)
5. The core components of this product, such as the compressor, controller, and electronic components, are all from internationally renowned brands.
6. This series of products includes quality inspection certificates and qualified labels from third-party authoritative organizations.
Structure
1. Structure：One machine.
2. Material：
a. Inner cavity SUS304 stainless steel
b. Outer box steel plate + powder spray paint or stainless steel
c. 100mm rigid polyurethane foam + fiberglass double-layer insulation
3. Box door：
a. Single door, buckle door lock.
b. Doors and windows are equipped with 3-layer vacuum layer observation windows, and a set of 11W Philips lighting lamps are included in the windows.
c. Window frames/door frames are equipped with electric heating (automatic adjustment) anti-frost and anti-condensation devices.
d. The door frame adopts high and low temperature resistant silicone rubber sealing strips.
air conditioning channel system
1. Working principle: Air is forced to circulate internally to balance temperature and humidity.
2. Air supply method: The top louver guide blade guides the air, then the upper air is supplied and the lower return air is forced to circulate.
3. Circulation fan: It adopts centrifugal high and low temperature resistant fan, driven by a long-axis external motor.
Parameter：
| Volume: | 30L |
| Inner box size: | Width 200 * Height 500 * Depth 300mm |
| Tensile machine size: | 950*700*1800mm (length*width*height) |
| Maximum force value: | 2000KG(2T) |
| power supply: | AC220V 50Hz±5Hz three-phase four-wire + protective ground wire |
| temperature control range | RT+10℃～ +150℃ (adjustable) |
| Heating rate | ≥4℃/min (no-load nonlinearity/slope) |
| temperature fluctuations | ≤±0.5℃ |
| temperature uniformity | ±2℃ |
| temperature deviation | ≤±2.0℃ |
| Test environment conditions | Room temperature 20±5℃, relative humidity ≤85%R.H, data measured after the temperature is constant under no load in the test chamber |
